EL Range 10×42 TA
$5,850.00
THE EL RANGE IS THE LATEST DEMONSTRATION OF THE INNOVATIVENESS THAT LIES AT THE HEART OF SWAROVSKI OPTIK. IT COMBINES SWAROVISION TECHNOLOGY WITH PRECISE RANGE MEASUREMENT.
MEASURE
The binoculars combine state-of-the-art optics with precise measuring functions.
The integrated tilt indicator with a unique angle shot program displays either the adjusted shooting distance or the angle. The EL RANGE gives you precise measurements from a distance of 10 meters (10.9 yards).
PERSONALIZED BALLISTICS
AIM
Use the smartphone app to configure the binoculars to your specific needs and individual ballistics data. Based on this and atmospheric data such as air pressure and temperature, it helps you to shoot with even greater precision because, along with the adjusted shooting distance, it also gives you the number of clicks needed for your rifle scope.
TRACKING ASSISTANT
FIND
The integrated Tracking Assistant makes it much easier to track your prey by guiding you to where you fired your last shot. You can opt to use this program via your phone or your EL Range.
SIZE & WEIGHT
169 mm
Lenght in mm.
136 mm
Width in mm.
79 mm
Height in mm.
925 g
Weight without batteries
Please phone store on availability on all Swarovski items.
Rivers to Ranges PH : 06 878 7177
Description
OBJECTIVE
10x
Magnification
42 mm
Effective objective lens diameter
4.2 mm
Exit pupil diameter
19 mm
Exit pupil distance
120 m/1000m
Field of view at m/1,000 m / ft/1,000 yds
6.8 °
Field of view degrees
6.8 °
Field of view with eye glasses (degrees)
61 °
Field of view apparent
5 m
Shortest focusing distance
± 5 dpt
Diopter adjustment
90 %
Light transmission
56-74 mm
Pupil distance
20.5
Twilight factor acc. to DIN-58388
MEASUREMENT
10 – 2000 m
Measuring range in yds./ m.
1 m
Measuring accuracy in yds./ m.
≤ 0.5 s
Measuring time
± 90 °
Angular measurement
Class 1 EN/FDA
Laser
Yard / Meter
Units
2,000 measurements
Life cycle
